DV5 Y Vertical Windlass

$6,715.50 – $10,000.65

SKU: DV-LCP - Categories: , Tag:

Description

The Dave DV5 Y is a vertical application windlass perfect for boats with limited deck space. This unit is composed of AISI 316 stainless steel which is a durable element when dealing with harsh marine environments. The unit comes in different variations such as with or without the drum capstan for rope retrieval, left and right side chain entry as well as various gypsy sizes for rope and chain retrieval. Equipped with an emergency manual lift system you can easily retrieve your anchor during instances when you may lose battery power on your boat. Additional features include an IP67 watertight motor, anodized aluminum gearbox, and an easy to open inspection lid. Dave DV5 Y is sold complete with the windlass, solenoid unit, clutch handle and mounting hardware.

Dave 1700 W DC 12 – 16 m 39 – 52 ft
Dave 2000 W DC 16 – 20 m 52 – 66 ft
Dave 2300 W DC 20 – 24 m 66 – 79 ft
Dave 3000 W DC 20 – 24 m 66 – 79 ft
Dave 3000 W AC 15 – 25 m 49 – 82 ft
Dave Hydro 15 – 25 m 49 – 82 ft

The indication may vary according to the boat type and the anchor-rode type

GYPSY 10 mm – 3/8″ 12/13 mm 14 mm
CHAIN 10 mm 10 mm 3/8″ 3/8″ 13 mm 12 mm 7/16″ 14 mm 14 mm 1/2″
DIN 766 ISO G4 BBB DIN 766 ISO G4 DIN 766 ISO G4
ROPE 3/4″ (19 mm) 3/4″ (19 mm) 3/4″ (19 mm)

The values in the table refer to a three-strand polyester rope with a rope/chain splice manufactured with the “Slim Splice Quick®” system.

Additional information

Weight N/A
Dimensions 17 × 17 × 11 in
Drum

Gypsy Size

, ,

Series

Wattage

1700W, 2000W, 2300W, 3000W
Voltage

12V, 24V

Specifications

Standard version
 Dave 1700 / 1700 D
Dave 2000 / 2000 D
 Dave 2300 / 2300 D Dave 3000 / 3000 D
Motor power 1700 W 2000 W 2300 W 3000 W
Motor supply voltage 12 V 24 V 24 V 24 V 24 V
Maximum pull 2425.1 lb 2645.5 lb 2777.8 lb 5300 lb 6834.3 lb
Maximum working load 1036.2 lb 1256.6 lb 1653.5 lb 1880 lb 2645.5 lb
Working load 341.7 lb 418.9 lb 551.1 lb 630 lb 881.8 lb
Current absorption @ working load (1) 175 A 100 A 115 A 120 A 145 A
Maximum chain speed (2) 118.4 ft/min 125.7 ft/min 135.2 ft/min 135 ft/min 128.6 ft/min
Maximum chain speed @ working load (2) 67.6 ft/min 68.2 ft/min 73.2 ft/min 76 ft/min 63.3 ft/min
Weight – Dave – [without drum] 74.1 lb 74.1 lb 86.6 lb 103 lb 135.1 lb
Weight – Dave D – [with drum] 81.6 lb 81.6 lb 94.1 lb 114 lb 142.6 lb
